48-Port Long-Range Gigabit Unmanaged PoE Switch, 400W
48-port long-range Gigabit unmanaged PoE switch with 2 Gigabit SFP uplinks, 400W PoE budget, wire-speed forwarding, VLAN, Extend, and watchdog.
Key features
- 48 Gigabit PoE ports and 2 Gigabit SFP uplink slots
- Ports 1–48 support IEEE 802.3af/at, up to 30W per port
- Smart watchdog, VLAN isolation, and Extend functions
- 400W total PoE power budget with built-in AC power supply
- 100Gbps non-blocking switching capacity and wire-speed forwarding
- Desktop, wall-mounted, or 19-inch 1U rack-mount installation
Specification
Interfaces
- Model
- PS14802SFG
- Fixed Ports
- 48 × 10/100/1000Base-T/TX PoE ports (data/power); 2 × 1000Base-X SFP uplink slots (data)
- PoE Standard
- Ports 1–48 support IEEE 802.3af/at, up to 30W per port
- Network Protocols
- IEEE 802.3 10BASE-T; IEEE 802.3i 10Base-T; IEEE 802.3x; IEEE 802.3u 100Base-TX; IEEE 802.3ab 1000Base-T; IEEE 802.3z 1000Base-X; IEEE 802.3u 100Base-FX
- Ethernet Port Features
- 10/100/1000Base-T(X) auto-detection, full/half duplex, auto MDI/MDI-X
- Fiber Port Features
- Gigabit SFP slots; fiber modules ordered separately, with single-mode/multi-mode and single-fiber/dual-fiber LC options
Switch Performance
- Switching Capacity
- 100Gbps, non-blocking
- Forwarding Rate
- 74.4Mpps
- MAC Address Table
- 8K
- Buffer Memory
- 4M
- Forwarding Mode
- Store and forward
- Twisted Pair Transmission
- 10BASE-T: Cat5 UTP up to 300m; 100BASE-TX and 1000BASE-T: Cat5 or later UTP up to 100m
- Power Supply Pin
- 1/2(+), 3/6(-)
- Maximum / Average Power per Port
- 30W / 15.4W
- Power Supply
- 400W, AC 100–240V, 50–60Hz
- Power Consumption
- Standby <15W; full load <400W
Physical Characteristics
- LED Indicators
- PWR (green); Link/Act for ports 1–50 (green)
- Operating Temperature / Humidity
- -20°C to +55°C; 5%–90% RH, non-condensing
- Storage Temperature / Humidity
- -40°C to +75°C; 5%–95% RH, non-condensing
- Installation
- Desktop, wall-mounted, or 19-inch 1U rack-mounted
- Protection
- IEC 61000-4-2 ESD: ±8kV contact, ±15kV air; IEC 61000-4-5 surge: power CM ±4kV / DM ±2kV, ports ±6kV
- Dimensions
- 440 × 290 × 44mm
- Net / Gross Weight
- <4kg / <4.5kg
- Protection Level
- IP30
Certification
- Certification
- CE, FCC, RoHS
Package Contents
- Switch
- 1 pc
- Power cord
- 1 pc
- Quick installation guide
- 1 pc
Interfaces
- Model
- PS14802SFG
- Fixed Ports
- 48 × 10/100/1000Base-T/TX PoE ports (data/power); 2 × 1000Base-X SFP uplink slots (data)
- PoE Standard
- Ports 1–48 support IEEE 802.3af/at, up to 30W per port
- Network Protocols
- IEEE 802.3 10BASE-T; IEEE 802.3i 10Base-T; IEEE 802.3x; IEEE 802.3u 100Base-TX; IEEE 802.3ab 1000Base-T; IEEE 802.3z 1000Base-X; IEEE 802.3u 100Base-FX
- Ethernet Port Features
- 10/100/1000Base-T(X) auto-detection, full/half duplex, auto MDI/MDI-X
- Fiber Port Features
- Gigabit SFP slots; fiber modules ordered separately, with single-mode/multi-mode and single-fiber/dual-fiber LC options
Switch Performance
- Switching Capacity
- 100Gbps, non-blocking
- Forwarding Rate
- 74.4Mpps
- MAC Address Table
- 8K
- Buffer Memory
- 4M
- Forwarding Mode
- Store and forward
- Twisted Pair Transmission
- 10BASE-T: Cat5 UTP up to 300m; 100BASE-TX and 1000BASE-T: Cat5 or later UTP up to 100m
- Power Supply Pin
- 1/2(+), 3/6(-)
- Maximum / Average Power per Port
- 30W / 15.4W
- Power Supply
- 400W, AC 100–240V, 50–60Hz
- Power Consumption
- Standby <15W; full load <400W
Physical Characteristics
- LED Indicators
- PWR (green); Link/Act for ports 1–50 (green)
- Operating Temperature / Humidity
- -20°C to +55°C; 5%–90% RH, non-condensing
- Storage Temperature / Humidity
- -40°C to +75°C; 5%–95% RH, non-condensing
- Installation
- Desktop, wall-mounted, or 19-inch 1U rack-mounted
- Protection
- IEC 61000-4-2 ESD: ±8kV contact, ±15kV air; IEC 61000-4-5 surge: power CM ±4kV / DM ±2kV, ports ±6kV
- Dimensions
- 440 × 290 × 44mm
- Net / Gross Weight
- <4kg / <4.5kg
- Protection Level
- IP30
Certification
- Certification
- CE, FCC, RoHS
Package Contents
- Switch
- 1 pc
- Power cord
- 1 pc
- Quick installation guide
- 1 pc
