AP306X AX3000 Wi-Fi 6 Ceiling Access Point
Model: AP306X
AC1200 Gigabit PoE Ceiling Access Point
High-power AC1200 dual-band ceiling AP for commercial use. Features Gigabit PoE, Mesh backhaul, and WPA3 security. Reliable solution for system integrators.
Key features
- 802.11AC 2.4G&5.8G 1200Mbps Indoor Wireless Ceiling AP
- 11AC Wave2 2.4GHz 300Mbps+5.8Ghz 866Mbps
- MTK chipset 512Mb 16b DDR2, 64Mb NorFlash, 200mW High-Power,access 128users
- 2* 4.5 dBi (2.4G ) + 2* 5dBi (5.8G ) inside antenna
- 1× Gigabit Port/POE，Support 48V200mA/802.3af Power Supply
- Supports AP mode, DHCP routing, up to 128 users, Wi-Fi hotspot and MESH backhaul
- WEB management, local firmware upgrade or centralized online upgrade; WPA/WPA2/WPA3 with mixed-user access
Specification
Hardware Specifications
- Model
- AP125
- Wi-Fi standard
Wi-Fi 5
5.8 GHz IEEE 802.11ac/n/a
2.4 GHz IEEE 802.11n/b/g
- Wireless speed
AC1200
5 GHz: 866 Mbps (802.11ac, VHT80)
2.4 GHz: 300 Mbps (802.11n)
- Antenna
5GHz 5 dBi, Omni-directional
2.4 GHz 4.5 dBi, Omni-directional
- Max EIRP
5 GHz 32 dBm
2.4 GHz 31.5 dBm
EIRP may be limited by country regulations
- SOC
- MIPS(580 MHz)
- RAM
- 512Mb 16b DDR2
- FLASH
- 64Mb NorFlash
- Interface
- 1× Gigabit Port/POE
- LEDs
- SYS
- Overall dimensions
- 210 x 22.3 mm (with an installation bracket of 8 mm)
- Work environment
Operating temperature: -10℃ to 45℃ Storage temperature: -40℃ to 70℃
Operating humidity: 10% to 90%RH (no condensation)
Storage humidity: 5% to 90%RH (no condensation)
- Protection level
- 15KV ESD
- Power consumption
- ≤10W
- Power supply method
- 48V300mA /802.3af/at,12VDC
- Packaging accessories
1 AP
4. Install screws
1. User manual
1. Warranty card
Software Specifications
- Work mode
- AP access point
DHCP routing
- Total number of users connected to the entire system
- 128
- Networking method
- WiFi hotspot
MESH backhaul
- Management approach
- WEB management
- Wireless Security
- WPA,WPA2,WPA3,and Pre-RSNA users are mixedly accessing the network.
- System update
- WEB Local upgrade,centralized management of online upgrade
Hardware Specifications
- Model
- AP125
- Wi-Fi standard
Wi-Fi 5
5.8 GHz IEEE 802.11ac/n/a
2.4 GHz IEEE 802.11n/b/g
- Wireless speed
AC1200
5 GHz: 866 Mbps (802.11ac, VHT80)
2.4 GHz: 300 Mbps (802.11n)
- Antenna
5GHz 5 dBi, Omni-directional
2.4 GHz 4.5 dBi, Omni-directional
- Max EIRP
5 GHz 32 dBm
2.4 GHz 31.5 dBm
EIRP may be limited by country regulations
- SOC
- MIPS(580 MHz)
- RAM
- 512Mb 16b DDR2
- FLASH
- 64Mb NorFlash
- Interface
- 1× Gigabit Port/POE
- LEDs
- SYS
- Overall dimensions
- 210 x 22.3 mm (with an installation bracket of 8 mm)
- Work environment
Operating temperature: -10℃ to 45℃ Storage temperature: -40℃ to 70℃
Operating humidity: 10% to 90%RH (no condensation)
Storage humidity: 5% to 90%RH (no condensation)
- Protection level
- 15KV ESD
- Power consumption
- ≤10W
- Power supply method
- 48V300mA /802.3af/at,12VDC
- Packaging accessories
1 AP
4. Install screws
1. User manual
1. Warranty card
Software Specifications
- Work mode
- AP access point
DHCP routing
- Total number of users connected to the entire system
- 128
- Networking method
- WiFi hotspot
MESH backhaul
- Management approach
- WEB management
- Wireless Security
- WPA,WPA2,WPA3,and Pre-RSNA users are mixedly accessing the network.
- System update
- WEB Local upgrade,centralized management of online upgrade
